Plastic Extrusion PVC Film Blowing Machine , 600 - 1000mm Width PVC Shrink Film Machine

Good quality Plastic Film Blowing Machine for sales
Good quality Plastic Film Blowing Machine for sales

——

I'm Online Chat Now

Plastic Extrusion PVC Film Blowing Machine , 600 - 1000mm Width PVC Shrink Film Machine

China Plastic Extrusion PVC Film Blowing Machine , 600 - 1000mm Width PVC  Shrink Film Machine supplier
Plastic Extrusion PVC Film Blowing Machine , 600 - 1000mm Width PVC  Shrink Film Machine supplier Plastic Extrusion PVC Film Blowing Machine , 600 - 1000mm Width PVC  Shrink Film Machine supplier Plastic Extrusion PVC Film Blowing Machine , 600 - 1000mm Width PVC  Shrink Film Machine supplier Plastic Extrusion PVC Film Blowing Machine , 600 - 1000mm Width PVC  Shrink Film Machine supplier Plastic Extrusion PVC Film Blowing Machine , 600 - 1000mm Width PVC  Shrink Film Machine supplier

Large Image :  Plastic Extrusion PVC Film Blowing Machine , 600 - 1000mm Width PVC Shrink Film Machine

Product Details:

Place of Origin: Shanghai
Brand Name: BEIYANG
Model Number: SJ65×29-SM1200

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: reconsideration
Packaging Details: 1 set with stretch film in the 45 foot high cabinets
Delivery Time: 60 work days
Payment Terms: T/T, L/C
Supply Ability: 30 units per year
Contact Now
Detailed Product Description
Unit-type: SJ65×29-SM1200 Width: 600-1000mm
Output: 70-80kg/h Screw Radio: 29:1
Main Motor: 30 Thickness: 0.03-0.06mm
DIe Diameter: φ150mm

Plastic Extrusion Process Plastic Film Manufacturing Machines 600-1000mm Width



PVC heat shrinkable film rotary blowing unit--SJ65×29-SM1200



Description:



No.1 traction and rotation refers that raw film blown by a mould is rotated and deflected at 180 to 320 degrees after entering into No.1 traction roller. By adopting DD-LTD brushless servo deviation-correcting device, raw film is transmitted to a water tank to be subjected to secondary inflation. During this process, water temperature control has a significant effect on thickness uniformity, and we adopt high-precision intelligent digit power regulator (SCR pulse control), the mutual deviation of water temperature is 80±0.1 DEG C, and it also has the energy-saving effect.



This machine is a technically patented product in 2016, at present it is put into volume production, welcome the domestic and overseas friends to visit and purchase.



Technical Data

Unit-type Width(mm) Output(kg/h) Screw radio (L/D) Main motor (KW)
SJ65×29-SM1200 600-1000 70-80 29:1 30





Plastic Extrusion PVC Film Blowing Machine , 600 - 1000mm Width PVC  Shrink Film Machine



Contact Details
Shanghai Bei Yang Plastic Machinery Limited company CO.,LTD.

Contact Person: Linda

Tel: +8615601800787
