Plastic Blown Film Extrusion Machine 70 - 80kg / H Output 1000mm Width

China Plastic Blown Film Extrusion Machine 70 - 80kg / H Output 1000mm Width supplier
Plastic Blown Film Extrusion Machine 70 - 80kg / H Output 1000mm Width supplier Plastic Blown Film Extrusion Machine 70 - 80kg / H Output 1000mm Width supplier Plastic Blown Film Extrusion Machine 70 - 80kg / H Output 1000mm Width supplier Plastic Blown Film Extrusion Machine 70 - 80kg / H Output 1000mm Width supplier Plastic Blown Film Extrusion Machine 70 - 80kg / H Output 1000mm Width supplier

Large Image :  Plastic Blown Film Extrusion Machine 70 - 80kg / H Output 1000mm Width

Product Details:

Place of Origin: Shanghai
Brand Name: BEIYANG
Model Number: SJ65×29-SM1200

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: reconsideration
Packaging Details: 1 set with stretch film in the 45 foot high cabinets
Delivery Time: 60 work days
Payment Terms: T/T, L/C
Supply Ability: 30 units per year
Contact Now
Detailed Product Description
Unit-type: SJ65×29-SM1200 Width: 600-1000mm
Output: 70-80kg/h Screw Radio: 29:1
Main Motor: 30 Thickness: 0.03-0.06mm
DIe Diameter: φ150mm

PVC heat shrinkable film rotary blowing unit--SJ65×29-SM1200



Description:



No.1 traction and rotation refers that raw film blown by a mould is rotated and deflected at 180 to 320 degrees after entering into No.1 traction roller. By adopting DD-LTD brushless servo deviation-correcting device, raw film is transmitted to a water tank to be subjected to secondary inflation. During this process, water temperature control has a significant effect on thickness uniformity, and we adopt high-precision intelligent digit power regulator (SCR pulse control), the mutual deviation of water temperature is 80±0.1 DEG C, and it also has the energy-saving effect.



This machine is a technically patented product in 2016, at present it is put into volume production, welcome the domestic and overseas friends to visit and purchase.



Technical Data

Unit-type Width(mm) Output(kg/h) Screw radio (L/D) Main motor (KW)
SJ65×29-SM1200 600-1000 70-80 29:1 30





Plastic Blown Film Extrusion Machine 70 - 80kg / H Output 1000mm Width
